Why can’t we simply replace lithium with sodium in batteries?

Author: Iñigo Careaga, strategy & communication manager, CIC energiGUNE

Lithium and sodium are neighbours in the periodic table. Both are alkali metals, both have a single electron in their outer shell, and both can be used to shuttle ions between two electrodes to store and release electrical energy. At first sight, replacing lithium with sodium in a rechargeable battery might therefore seem straightforward.

There are good reasons to try. Sodium is widely available and sodium-ion batteries can rely on electrode materials containing abundant elements such as iron and manganese. But chemical similarity does not mean electrochemical equivalence. A sodium ion is larger and heavier than a lithium ion, and its interaction with the materials surrounding it is different. As a consequence, replacing Li⁺ with Na⁺ changes much more than the identity of the charge carrier.

The electrodes have to accommodate a different ion. Their structures may respond differently as sodium is inserted and removed. The electrolyte has to transport and solvate it. New interfaces form between the electrolyte and the electrodes. Even graphite, the standard anode material of most commercial lithium-ion batteries, does not store sodium under conventional conditions nearly as effectively as it stores lithium ¹.

A sodium-ion battery is therefore not simply a lithium-ion battery containing a different element. Understanding why requires looking at what happens to sodium once it enters the battery.

Graphite does not play by the same rules

Charging a conventional lithium-ion battery involves moving lithium ions from the positive electrode through the electrolyte and storing them in the negative electrode. Graphite is particularly good at this job. Its carbon atoms are arranged in sheets, and lithium can reversibly occupy the spaces between them, a process known as intercalation. It would be convenient if sodium behaved in the same way. It largely does not.

The poor ability of conventional graphite to accommodate sodium has long been one of the reasons why lithium-ion concepts cannot simply be transferred to sodium-ion batteries. Instead, one of the most widely studied negative-electrode materials is hard carbon ².

Hard carbon is still carbon, but structurally it is very different from graphite. Rather than a regular stack of extended carbon sheets, it contains disordered graphitic domains, defects and pores. This disordered architecture provides environments in which sodium can be stored, but it also makes the underlying mechanism considerably harder to describe.

Where exactly does the sodium go? Researchers have proposed contributions from adsorption at defects and surfaces, insertion between graphitic layers and storage associated with nanopores. The relative importance of these mechanisms depends on the structure and microstructure of the carbon. This is more than a microscopic detail: where and how sodium is stored determines the voltage profile, reversible capacity, first-cycle losses and, ultimately, the energy that a complete cell can deliver.

Researchers at CIC energiGUNE and collaborators have studied this connection between charge-storage mechanisms, carbon structure and electrochemical performance ³. Their analysis highlights an important point: maximizing the amount of sodium that an anode can store is not enough. The potential at which that storage occurs and the irreversible losses during the first cycle are equally important when the material is incorporated into a full battery.

The problem is therefore not simply to find a carbon that accommodates more sodium. It is to understand how its structure stores sodium and then engineer that structure so that capacity, voltage and efficiency improve together. This has led researchers to explore different ways of controlling hard-carbon structure, including the use of lignocellulosic biomass as a precursor. Work has shown that even apparently simple processing decisions, such as acid treatment of the biomass precursor, can affect the resulting carbon and its behaviour as a sodium-ion anode ⁴.

And the negative electrode is only half of the problem. At the positive electrode, sodium ions have to repeatedly leave and re-enter a solid structure. Layered transition-metal oxides are attractive candidates because sodium can be reversibly extracted from and inserted into spaces between layers of metal and oxygen atoms. Compositions based on relatively abundant elements such as iron and manganese are particularly interesting ⁵.

Again, however, accommodating sodium is not enough. The host structure has to survive the process. A useful example is the layered oxide P2-Na₂/₃[Fe₁/₂Mn₁/₂]O₂, investigated by researchers from CIC energiGUNE and collaborators ⁶. The material can provide high capacity, but its long-term stability strongly depends on the voltage range over which it is operated.

This produces a familiar battery dilemma. Increasing the operating voltage can increase the amount of energy extracted from a material. But pushing the electrode further can also trigger structural transformations that make subsequent cycles less reversible.

The researchers compared cells operating in different voltage windows and combined electrochemical measurements with structural characterization and theoretical calculations. Above approximately 4.0 V versus Na+/Na, the cathode undergoes a high-voltage phase transition. Avoiding this transition improves capacity retention, revealing a direct connection between the structural state of the electrode and its long-term electrochemical behaviour.

Changing the chemical composition can also alter this structural response. In another study, researchers investigated the effect of introducing titanium into sodium manganese-rich layered oxides ⁷. A certain degree of Ti substitution helped the crystal structure accommodate electrochemically induced strain. Too little was insufficient to stabilize it, while further substitution introduced other destabilizing effects.

Other studies have approached the same problem from a different angle, examining how the precise stoichiometry of P2 layered oxides affects their performance ⁸, or following their structural evolution under different current rates and dopants using operando techniques ⁹. The lesson is that there is no single property called “a good sodium cathode”. Composition, atomic arrangement, voltage and cycling conditions are interconnected. Even an element that does not directly provide the stored charge can determine how well the electrode survives sodium repeatedly moving through its structure.

A different chemistry

Layered oxides are not the only possible positive electrodes. Sodium chemistry allows other structural families to be explored.

One particularly instructive example is NaFePO₄, the sodium analogue of the well-known lithium iron phosphate chemistry. Researchers involving CIC energiGUNE have used in situ X-ray diffraction to follow how NaFePO₄ changes during sodium insertion and extraction ¹⁰. They have also shown that the reaction mechanism itself depends on how rapidly the electrode is charged or discharged ¹¹.

This is a subtle but important point. We often describe an electrode material as if it had a fixed reaction mechanism. In practice, what happens inside it can depend on how the battery is operated. Computational work has gone further by investigating sodium diffusion in NaₓFePO₄ ¹². Combining experiments and modelling in this way makes it possible to connect what is observed at the battery level with the motion of ions through an atomic structure.

But even understanding both electrodes is not enough. Between them lies the electrolyte, and the sodium ion spends much of its journey there. It becomes surrounded by solvent molecules, travels across the cell and eventually reaches an electrode surface. At that interface the electrolyte can decompose, producing a solid-electrolyte interphase, or SEI.

This apparently thin layer can have a disproportionate influence on battery behaviour. Researchers at CIC energiGUNE have investigated both the composition and evolution of the SEI in sodium-ion electrodes ¹³ and, more broadly, the relationship between electrode-electrolyte interphases, transport properties and electrochemical performance in non-aqueous sodium-ion batteries ¹⁴.

The interface illustrates particularly well why changing lithium for sodium is not a simple substitution. The chemistry of the ion influences its solvation, its transport and the decomposition reactions that occur when it reaches an electrode. A material that can reversibly store sodium may still perform poorly if the interface around it continuously consumes electrolyte or sodium during cycling.

This is why sodium-ion research has to consider the cell as a system. Graphite may have to give way to hard carbon. Positive electrodes require structures able to tolerate repeated sodium insertion and extraction. Electrolytes and additives have to create suitable transport conditions and stable interfaces.

And every attempt to solve one of these problems can affect the others.

Sodium is not the new lithium

Lithium has a fundamental advantage that materials engineering cannot simply remove: it is the lightest metal and has a very low electrochemical potential. Sodium is heavier and its electrochemical potential is less favourable, placing intrinsic constraints on the gravimetric energy density that sodium-ion batteries can reach.

That does not necessarily make sodium a worse battery chemistry. Energy density is only one parameter of an electrochemical storage system. Cost, raw-material availability, lifetime, power, safety and operating temperature can become equally important depending on the application. A battery designed for a mobile phone, an electric vehicle or stationary storage does not necessarily have to optimize the same variables. And sodium chemistry itself offers several possible ways of balancing them.

CIC energiGUNE researchers have explored, for example, low-cost phosphate-based cathodes for aqueous sodium-ion batteries ¹⁵, Prussian Blue compounds as positive electrodes in aqueous systems ¹⁶, alternative sodium layered oxides [5,8,9], hard-carbon anodes [2,3,4] and even materials such as NaTiOPO₄ designed to modify or potentially avoid some of the interfacial problems normally associated with sodium-ion anodes ¹⁷.

These are not different routes towards exactly the same battery. They represent different ways of deciding which compromises are acceptable.

This changes the original question. The relevant challenge may not be how to make sodium behave as much like lithium as possible. Research on hard carbons shows that sodium may require a different type of host structure. Work on layered oxides shows that extracting more energy from an electrode can alter its structure and compromise its stability. Studies of NaFePO₄ show that the reaction pathway itself can depend on cycling conditions. And research on interfaces shows that storing sodium reversibly is only part of the problem: the chemistry taking place around the active material matters as well.

Sodium-ion batteries are therefore not lithium-ion batteries in which one element has simply been exchanged for another. Changing the ion changes the materials that host it, the structures they adopt, the reactions they undergo and the interfaces they form.

Sodium may not need to beat lithium at its own game. The more interesting question is whether understanding its different chemistry will allow us to play a different one.
